Manual powder cabins
Extraction of coating powder
Special solutions are also possible
Catalog Powder Coating Equipment
6-8 weeks delivery time
Hanging cubicles
1 - 5 filter cartridges possible
Lighting, exhaust air filter
Powder chamber
100% polyester or nano-coated filters
Pneumatic cleaning of the filters
Manual walk-through booths
3 - 10 filters possible
Lighting, large post-filter unit
Powder chamber or cyclone separator
Automatic cleaning of the filter cartridges
100% polyester or nano-coated filters
Dimensions inside
Usable area in meters
| Type FK Filter | A width | B height | C depth * incl. filter |
|---|---|---|---|
| 1 | 0,9 | 1,25 | 1,1 |
| 2 | 1,04 | 1,25 | 1,6 |
| 3 | 1,05 | 1,4 | 1,8 |
| 3 SO | S eitlich | O ffen | 1.8 pass |
| 4 | 1,3 | 1,4 | 1,8 |
| 4 SO | S eitlich | O ffen | 1.8 pass |
| 5 | 2,4 | 1,85 | 1,93 |
| 5 Cars | 2,4 | 1,4 | 1,86 |
| 6 | 3,5 | 1,67 | 0.5 pass |
| 8 | 3,5 | 1,56 | 0.6 pass |
| 10 | 4,5 | 2,1 | 0.8 pass |
Or inquire about your desired size!
sketch
Some variations of the powder extraction walls
3 Filter
3 Car filters
5 Car filters
Large post-filter
Automatically and manually
With chain conveyor
Purely automatically
Cyclone separator
Steel or plastic cabin
